SCI Video Systems 560IV7BosD

SCI Video Systems 560IV7BosD

• Image sensor: 1/3" SONY SUPER HAD CCD
• Effective Pixels: NTSC:768x494 PAL:752x582
• IRLEDs: 42pcs ^5mm(30m), 75pcs ^5mm(50m), 12pcs ^10mm(80M)
• Signal System: NTSC/PAL
• Horizontal Resolution: 600TVL
• Minimum Illumination: 0.1 Lux (F1.2,501 RE,AGL ON)
• Electronic Shutter: Auto:1/50(1/60)-1/100,000Sec
• S/N Ratio: >60dB
• Gamma: 0.3~1.0 adjustable
• Lens: 9-22mm
• Video Output: 1.0Vp-p, 75Ω
• IR Wave Length: 850nm
• Power Consumption: 2.5W; 7W(IR)
• IR Distance: 15M
• Video Output: BNC Connector
• Power Supply: DC 12V/AC 24V
• Operating Humidity: 20~80%
• Operating Temperature: -10C ~ +501C (-14F ~ +122F)
• Environment: Outdoor
• Weight: 1.20kg
